Emounting Outlet Webshop (EOW) Horizontale 12" Swing Arm Mount voor Fishfinders & Plotters
De RAM dubbele scharnierarmhouder bevat twee 6" lange gebogen scharnierarmen gemonteerd op een horizontale oppervlakte montagebasis. Aan het apparaatmontageeinde van de beugel is een rechthoekige 6,25 x 2" bovenste basis. De draaipunten van de beugel staan een volledige 360 graden rotatie toe.
Features
- Universele drill-down visvinder montageoplossing met twee maal 15,24 cm (6 ") zwenkarm voor optimale apparaatplaatsing
- Drie draaipunten stellen volledige 360-graden rotatie in staat.
- Gemaakt van poedercoating staal en hoogwaardig composiet
Emounting Outlet Webshop (EOW) lichte transport schade (krasjes).
Non-returnable: Vanwege de scherpe afprijzingen op deze EOW onderdelen wordt er door ons geen recht op retour gegeven.
Dimensions:
A. Center of knob to center of ball socket: 6" (15,2 cm)
B. Overall length of swing arm assembly: 10.75" (27,3 cm)
C. Overall height: 5.6" (14,2 cm)
D. Height from base to top of knob: 4.91" (12,5 cm)
Material:
Powder Coated Marine Grade Aluminum
Mount Components included
BASE: RAM-111BTU
ARM: RAM-109-1APU
BASE: RAM-109H-B
The RAM-111BT universal base has a short post connected at right angles to a flat 6.25 x 2 inch rectangular base. The base has many different combinations of pre-drilled holes which will match up to many electronic devices and mounts, including Marine GPS, CB Radios, Ham Radios, Gimbal Brackets and more. The small post on the base is designed to connect to the RAM-109 series arms. Included on the end of the post is a tightening knob for use when installed on the compatible RAM-109 series arm.
Compatible Makes & Models
GARMIN FISHFINDER 320C
GARMIN GPSMAP 180
GARMIN GPSMAP 182
GARMIN GPSMAP 182C
GARMIN GPSMAP 185 SOUNDER
GARMIN GPSMAP 188 SOUNDER
GARMIN GPSMAP 188C SOUNDER
GARMIN GPSMAP 192C
GARMIN GPSMAP 198C SOUNDER
Compatible Makes & Models
GARMIN GPSMAP 2106
GARMIN GPSMAP 2206
GARMIN GPSMAP 230
GARMIN GPSMAP 232
GARMIN GPSMAP 235 SOUNDER
GARMIN GPSMAP 238 SOUNDER
GARMIN GPSMAP 3005C
GARMIN GPSMAP 3006C
GARMIN GPSMAP 3205
Compatible Makes & Models
GARMIN GPSMAP 3206
LOWRANCE LCX-104C
LOWRANCE LCX-110C
LOWRANCE LCX-17M
LOWRANCE LCX-19C
LOWRANCE LCX-20C
LOWRANCE LCX-25C
LOWRANCE LCX-26C HD
LOWRANCE LMS-332C
C
HUMMINBIRD 947C 3D COMBO
HUMMINBIRD 931C
HUMMINBIRD 937C COMBO
HUMMINBIRD 981C SI
HUMMINBIRD 987C SI COMBO
HUMMINBIRD MATRIX 97
